GPSMAP 60CS

The GPSMAP® 60CS and GPSMAP 60C are new all-purpose units—packed with exciting new features and delivering the kind of color that consumers want in their handheld GPS’s. These lightweight, rugged, waterproof units raise the bar to offer a 256-color, highly reflective display that provides easy viewing in almost any lighting condition. This transreflective TFT provides excellent viewing while maximizing your battery life (20 hours, typical use).
Both the GPSMAP 60CS and GPSMAP 60C are packed with extra features, including rapid automatic route calculation, an integrated outdoor calendar, a dedicated geocaching mode, and indoor/outdoor GPS games that turn the outdoors into a giant gameboard.
The GPSMAP 60CS also offers an electronic compass and barometric altimeter for highland adventures. These sensors, when combined with GPS technology, provide enhanced bearing and elevation readings.

GPSMAP 60CS Features:

• Electronic compass displays accurate heading while standing still


• Barometric sensor with automatic pressure trend recording


• Sunlight-readable display with 256-color transreflective TFT display (1.5" W x 2.2" H; 2.6" diagonally); color operating system with new look-and-feel


• Faster processor, with auto routing, turn-by-turn directions, and audio alerts along city streets or trails when using MapSource® City Select® or 24K Topo software (optional software)


• 56 MB of internal memory for storing map detail


• Permanent user data storage


• Each day’s best hunting and fishing times—along with sunrise/sunset times—on the integrated Outdoor Calendar


• Special geocaching navigation mode


• Geolocation games, such as Virtual Maze, Nibbons, Geko™ Smak, Memory Race, and Gekoids


• Fast map transfer, with support for both USB and serial port interfaces


• Detailed basemap with general map data, including highways, major roads, river, lakes, and borders


• Dedicated "mark", "page", "enter", "quit", "menu", "find", and "zoom out/in" buttons; four-position rocker pad


• 2.4" x 6.1" x 1.3" (W x H x D) unit dimensions


• Weighs 5.4 ounces (without batteries), 7.5 ounces (with batteries)


• WAAS GPS receiver with accuracy to 10 feet in North America; built-in quad-helix antenna for better satellite reception


• 20 hours of battery life under typical-use conditions (uses two "AA" batteries)


• Multi-platform navigation for easy navigation in a car, in a boat, or on foot


• Accepts data from MapSource products. See the MapSource Compatibility table (top right) for a list of software that Garmin recommends with this product.
  Waterproof to IEC 60529 IPX7 standards (can be submerged in one meter of water for up to 30 minutes)


• 50 reversible routes, 10,000 track points with TracBack® technology (navigate to any track point on the displayed map), and 1000 waypoints with additional graphical icons for location identification


• Proximity alerts for anchor drag, arrival, off-course, proximity waypoint; built-in alarm clock


• User-configurable track-line color, waypoint projection, display color scheme, large-numbers option, audio tones, and pages (turn on/off main pages or change the sequence in which they appear)


• Elevation computer provides current elevation, ascent/descent rate, minimum and maximum elevation, total ascent and descent, average and maximum ascent and descent rate


• Trip computer provides odometer, stopped time, moving average, overall average, total time, max speed, and more

GPSMAP 478

On land or water, you're ready to go
Go n land or water, you're ready to go from box to boat to dash with the portable and versatile GPSMAP® 478. This combination color chartplotter and land navigator comes preloaded with U.S. marine charts utilizing elements of the latest BlueChart® g2 technology, in addition to detailed street-level mapping. Optional weather and sonar capabilities combined with the ability to conveniently add plug-in data cards, let you easily add more maps and features — making this one incredible GPS navigator for land and sea.
Preloaded and Portable
From curbside to dockside, the GPSMAP 478 has you covered — no downloads or computer required. Its built-in marine charts utilize the latest BlueChart® g2 technology and feature coverage for all U.S. coastal areas, including Alaska and Hawaii. Our g2 mapping technology offers a smoother, more fluid presentation on your screen.
For road trips, the 478 along with its freshwater counterpart, the GPSMAP 378, come preloaded with City Navigator NT detailed street maps for North America and include automatic routing with voice guidance along with an industry-leading database with more than six million points of interest — including hotels, restaurants, gas stations, marinas, attractions and more. An included marine mount and automotive kit make it a snap to transfer the unit from boat to car.
Up-to-date Weather
See real-time weather displayed on the 478’s high-resolution 256-color sunlight-readable TFT display with the purchase of the GXM 30 antenna (sold separately) and subscription to XM WX Satellite Weather. View vital weather data, such as NEXRAD radar, storm cells, wind speeds, surface temperatures, forecasts and more than a dozen other weather attributes directly on the unit’s display — so you can spend more time enjoying the water and less time worrying about the weather.
With the GXM 30 antenna, you also have the option of receiving XM Satellite Radio’s 150 plus channels of commercial-free music, sports, news, talk and entertainment programming. Weather and audio options travel with your plotter, whether you’re navigating on land or sea.
Sonar Capability
If fishing’s your game, pair the 478 with the GSD™ 21 remote sounder module to add sonar capability. The GSD 21 is Garmin’s “black box” sounder, which offers 4,000 watts of power peak-to-peak (500 watts RMS) in a dual-frequency transducer (purchased separately).
Plug-and-play Additional Mapping
Optional software available on plug-in Garmin data cards, lets you instantly add new maps to your GPSMAP 478 — without connecting to your computer. Easily customize map data for your adventures on land or sea with our optional MapSource® cartography. Plug-in the latest BlueChart g2 data cards to add “real picture” aerial photo reference, detailed coastal roads and points of interest. For inland coverage, try our preprogrammed U.S. Inland Lake data cards. See the MapSource Compatibility table (top right) for a list of software that Garmin recommends with this product.
The GPSMAP 478: Loaded and ready for action, right out of the box

GPSMAP 478 Features:

• Receiver: WAAS-enabled, 12 parallel channel GPS receiver
• Display: 3.8-inch diagonal, 480 x 320 pixel, 256-color TFT screen with adjustable LED backlight
• Unit dimensions: 5.7"W x 3.2"H x 1.9"D
• Waypoints: Stores 3,000 waypoints and 50 reversible routes
• Tracks: 10,000 point automatic track log saves up to 15 tracks
• Battery life: Rechargeable lithium-ion battery offers 4 to 15 hours of use (4 hours with GXM 30 and 15 without GXM 30)
• Water resistant up to IEC 60529 IPX7 standards (submersible in one meter of water for 30 minutes)
• Preloaded with U.S. marine detail charts utilizing g2 technology
• Built-in street navigation with voice prompts, using included cable and speaker
• Accepts the latest (optional) BlueChart g2 data cards
• Add optional GSD 21 for full-feature sonar capability
• Add optional GXM 30 antenna for XM WX Satellite Weather
• Provides tides and built-in celestial information
• NMEA 0183 input and output
• Removable quad helix antenna
• Single knob tilt/swivel mount

MOTOROLA - GP338 Plus

Motorola GP338 Plus display radio - the smallest in Motorola’s Professional Series. It is compact, light and fit easily into the palm of your hand. A versatile alternative for those who require additional features to meet expanding communication needs.

Advanced Audio Technology
Motorola’s special voice compression and low level expansion technology enable crisper, clearer and stronger audio quality, allowing you to keep communicating even in a noisy environment.

Features Overview
Highlights of the GP338 Plus
Signalling - Quick Call II, DTMF, limited MDC1200
Power Output - 6W 5W (VHF) 4W (UHF)
Option Board - Yes
Keypad - Yes
Display - Yes
Emergency Button - Yes
Battery Life - 8 hours (High Power), 10 hours (Low Power) - With Slim Lilon battery
MilSpec - MIL-STD 810C, D & E
Intrinsically Safe - Yes
Weight (gm/kg) - 265gms ( With Slim Lilon battery)
Frequency - 136-174MHz / 330-400MHz / 403-470 MHz/ 450-527MHz
Channels - 128
Dimension (H X W X D) - 101.5 mm x 55.5 mm x 33 mm ( With slim Lilon battery)

Versatile
Motorola’s unique MDC signalling allows the transfer of data communications at the high speed rate of 1200 bits per second.
The Forward error correction technology enables radio to receive message, like PTT-ID display, radio status and send out remote killing signal or emergency call even though the voice signal is too weak to be heard.
Large display with 14 Character Alpha Numeric Dot Matrix allows immediate communication of vital information. The keypad & display illuminations provide the needed visibility to operate your radio in the dark.
Name and tone tagging with capability to assign 8 different ringing tones and visual caller ID to 8 specific users/ talkgroups
The built-in voice-activated feature (VOX) enables users to transmit their message in a hands-free environment, without pressing the push-to-talk button.
The GP338 Plus is intrinsically safe to operate in hazardous atmosphere by the US Factory Mutual standard.
Proving up to a maximum of 128 channels allow greater flexibility in organising different work group.

Compact but Rugged
Motorola’s Accelerated Life Test
MIL-STD 810C, D and E

MOTOROLA - GP338

The 128-Channel GP338 is essential for growing organisations because of its unique versatility. Whatever your profession, this is the radio that grows with you.

Unsurpassed Audio Quality
Motorola's special voice compression and expansion technology called X-PAND enables crisper, clearer and stronger audio quality, allowing you to keep communicating, even in noisy environment.

Features Overview
Highlights of the GP338
Signalling - Quick Call II, DTMF, limited MDC1200
Power Output - 5W (VHF) 4W (UHF)
Option Board - Yes
Keypad - Yes
Display - Yes
Emergency Button - Yes
Battery Life - 8 hours (High Power), 10 hours (Low Power) - With Standard Hi- Capacity NiMH battery
MilSpec - MIL-STD 810C, D & E
Intrinsically Safe - Yes
Weight (gm/kg) - 428gms (With Standard Hi-Cap.NiMH battery)
Frequency - 136-174MHz / 330-400MHz / 403-470 MHz/ 450-527MHz
Channels - 128
Dimension (H X W X D) - 137 mm x 57.5 mm x 37.5 mm ( With Standard Hi-Cap.NiMH battery)

Powerful
Motorola’s unique MDC signaling allows the transfer of data communications at the high-speed rate of 1200 bits per second.
The Forward error correction technology enables radio to receive message, like PTT-ID display, radio status and send out remote killing signal or emergency call even though the voice signal is too weak to be heard.
Expandable & easy to install in the field, by adding option boards like voice storage board & DTMF Decoder boards whenever your needs arise. The option board also allows up to 2 minutes of recording.
The plug-in mandown option board feature will trigger an emergency procedure in situations where the radio is horizontal or still for longer than a pre-programmed time. It is critical for radio users who work alone or in isolated environments.
The GP338 is certified by the US Factory Mutual standard intrinsically safe to operate in hazardous atmosphere.
The built-in voice-activated feature (VOX) enables users to transmit their message in a hands-free environment, without pressing the push-to-talk button.

Versatile
Large display with 14 Character Alpha Numeric Dot Matrix allows immediate communication of vital information. The keypad & display illuminations provide the needed visibility to operate your radio in the dark.
Received Signal Strength Indicator displays signal strength in the vicinity where you operate in.
Name and tone tagging with capability to assign 8 different ringing tones and visual caller ID to 8 specific users/ talkgroups
Easy-to-access, one-touch Emergency Siren button with piercing alarm to seek help in critical situation.
Lightweight Lithium Ion battery option makes the radio one of the lightest in its range.

Compact & Reliable
Motorola's Accelerated Life Test.
MIL-STD 810 C, D & E.

Diamond SG2000 Monoband Mobile Antenna

One of Diamond® Antenna's Supergainer® Premium mobile antennas.

• Fold-Over
Special Features:• Hi-Power – 250 watts• Factory pre-tuned, no adjustment• Highest gain • Wideband performance • 24Kt gold plated connector pin
Specifications:
Bands: 2m
Gain dBi: 5.2
Watts: 250
Height: 62"
Mount: UHF
Element Phasing: 1/2l + 3/8l
